Product Info:

• Compensation Free Trinocular Head, Inclined at 30°（50mm-75mm)
• Eyepiece:  WF10×/25mm, WF10×/20mm,crosshair with reticule 0.1mm
• Long working distance bright and dark field
• Infinity Plan Objectives:5x/0.1B.D/W.D.29.4mm,10x/0.25B.D/W.D.16mm, 20x/0.40B.D/W.D.10.6mm,40x/0.60B.D/W.D.5.4mm
• Quintuple Nosepiece with DIC Jack
• Double layer mechanical stage, Stage Size: 190mm×140mm
• Moving Range: 50mm×40mm, Flashboard type filters(green, blue, neutral)
• Coaxial coarse & fine focusing adjustment with rack and pinion mechanism
• Fine focusing scale value 0.002mm with aperture iris diaphragm and field iris diaphragm
• Halogen bulb 12V/50W,AC85V-230 ,Brightness adjustable
• Analyzer rotable360°
• Polarizer&Analyzer can be moved in/out of the optical path 0.01mm Micrometer
