CPU

Quad-core 1.5 GHz, 64-bit ARM Cortex-A53

Memory

512 MB DDR4 RAM

Flash

8 GB eMMC

Channel

8 (Half/Full-duplex)

Frequency Band

CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4

Sensitivity

-140dBm Sensitivity @292bps

Tx Power

27dBm Max

Protocol

V1.0 Class A/Class B/Class C and V1.0.2 Class A/Class B/Class C

Port

1 × RJ45 WAN Port (PoE PD supported)

Physical Layer

10/100/1000 Base-T (IEEE 802.3)

Data Rate

10/100/1000 Mbps (Auto-Sensing)

Interface

Auto MDI/MDIX

Mode

Full or Half Duplex (Auto-Sensing)

Ethernet Isolation

1.5 kV RMS

Antenna

Internal Antenna

Standards

IEEE 802.11 b/g/n, 2.4GHz

Tx Power

802.11b: 18 dBm +/-2.0 dBm (11 Mbps)

802.11g: 15 dBm +/-2.0 dBm (6 Mbps)

802.11g: 15 dBm +/-2.0 dBm (54 Mbps)

802.11n@2.4 GHz: 14 dBm +/-2.0 dBm (MCS0_HT20)

802.11n@2.4 GHz: 14 dBm +/-2.0 dBm (MCS7_HT20)

802.11n@2.4 GHz: 13 dBm +/-2.0 dBm (MCS0_HT40)

802.11n@2.4 GHz: 13 dBm +/-2.0 dBm (MCS7_HT40)

Network

4G LTE

SIM Slot

1 (mini SIM-2FF)

Reset Button

1 × RST

USB

1 × USB Type-C for Power Supply and Console

LED Indicators

1 × POWER, 1 × STATUS, 1 × LoRa, 1 × Wi-Fi, 1 × LTE, 1 × ETH

Power Connector

1 × DC Male Jack Connector (2.1 x 5.5 mm)

Built-in

Watchdog, RTC, Timer

Power Input

1. DC 9-24 V by Power Connector

2. 802.3 af PoE

3. 5V/1A by USB Type-C Port

Power Consumption

Typical 2.9 W, Max 4.2 W

Ingress Protection

IP65

Material & Color

PC+ABS (UL94 V0), White & Black

Weight

548g

Dimensions

180 x 110 x 55.5 mm (7.09 x 4.33 x 2.19 in)

Installation

Desktop, Wall or Pole Mounting

Operating Temperature

-40°C to +70°C (-40°F to +158°F)

Reduced Cellular Performance Above 60°C

Storage Temperature

-40°C to +85°C (-40°F to +185°F)

Relative Humidity

0% to 95% (non-condensing) at 25°C/77°F

Regulatory

CE, FCC, IC, Telec, JATE, RCM

Environmental

RoHS, REACH
